Specifications
- Cabinet size 43″(h) 24″(d) 25″(w) / 109(h) 61(d) 65(w)cm
- Work surface height 43″
- No monitor — all computing and user interface conducted on the facility’s NexsysADC main cabinet or 4T countertop unit
- Weight 140 lbs (empty) up to 350 lbs (with 10 CAMs)
- Capacity up to 400 SKUs (highly configurable)
- CAMs (Controlled Access Module)
- Configured for up to 25 SKUs; 12 CAM configurations available
- CAM size 16.25″w x 13.375″d x 3″h
- 1×1 cell 2.76″w x 2.37″d x 2″h
- 1×2 cell 5.78″w x 2.37″d x 2″h
- 2×2 cell 5.78″w x 4.86″d x 2″h
- Open cell medication bins for routine meds: 2-Tier and 3-Tier
- Each bin can be adjusted for 1 to 14 locations. These medications are also tracked.
- 2-tier (6 individual bins): 18″w x 16″d x 6.5″h, 15 lbs
- 3-tier (9 individual bins): 18″w x 16″d x 9.75″h, 21.5 lbs
- Single cassette bin: 5.25″w x 11.5″d x 2.5″h
- Positions per bin: Can contain up to 14 positions per bin. Positions can be combined by removing dividers.
- Supply drawers: Available in 3″, 6″ or 9″ depth
- Each drawer can be adjusted for 1 to 24 positions
- 3″ drawer: 17″w x 14.75″d x 3″h
- 6″ drawer: 17″w x 14.75″d x 6.5″h
- 10″ drawer: 17″w x 14.75″d x 9.75″h
- Built-in uninterrupted power supply (operation 6+ hours)
- Power requirements: Standard dedicated universal outlet
- UL tested & approved
